Print your floor plan (export to PDF)

Open Export / Print / Share → PNG/JPG/PDF or Print. The Print tab sends the plan to your printer; the Export tab saves a PDF (or a PNG or JPG image) you can print anywhere. Best results: black & white with measurements.

3 min readUpdated 2026-11-17

There are two ways to get your plan onto paper, both in the same dialog: Print sends it straight to your printer, and Export → PDF saves a print-ready file you can print later, email, or take to a print shop. Either way the plan fills the page instead of printing tiny in a corner.

The same dialog also saves the plan as a PNG or JPG image. For paper, a PDF is the better choice: it comes sized to the sheet you pick and keeps every line crisp, while an image leaves the page size to whatever program you print it from.

Step by step

  1. 1

    Open the Print / Export dialog

    Click Export / Print / Share in the top bar and choose PNG/JPG/PDF or Print (Print, or save as an image or PDF). The Export / Print Floor Plan dialog opens with two tabs: Print and Export.

    Export / Print / Share → PNG/JPG/PDF or Print.
  2. 3

    Export tab: save a print-ready PDF

    On the Export tab, set Format to PDF (Print / email); the three format tiles are PNG, JPG and PDF. Under Paper size & quality, pick the paper you'll print on (A3 up to A0, Tabloid, ARCH D, ARCH E) and a quality, or leave Standard for an email attachment. Click Export PDF and the file downloads. The PDF's page follows that choice. In our test export of the Medium 2-Bedroom Apartment template, Standard gave a Letter-size landscape page (11 × 8.5 in, 335 KB) and A3 + High an A3 landscape page (420 × 297 mm, 486 KB, with the plan rendered at 3638 × 3388 pixels). The plan is stored in the PDF without JPG-style compression, so its lines and small numbers print as sharp as a PNG.

    Export tab → PDF, with the paper size you'll print on.
  3. 4

    Pick a view, then fine-tune the options

    Both tabs share the same Views row and Options. The Views (added November 17, 2026) are the same as in View & Layers: Floor plan (measurements, room names, furniture, room tints), Interior design (furniture with names, flooring, tile layouts, room tints) and Electrical plan (outside measurements, room names, outlets, switches, lights, circuit lines and the Symbol legend & circuit table), plus any view you saved. Ticking a view ticks its options; unticking it unticks them unless another ticked view has them; ticking a single option never changes the views. They start ticked the way they are in View & Layers. Then fine-tune the options. For a working drawing: - Black & white = on: strips colors for a pure line drawing - Furniture = on or off: every piece of furniture, appliance and fixture except electrical symbols and lights. Untick it for an empty plan or an electrician's plan (next step) - Electrical symbols = on if the plan has outlets, switches, lights or other plan symbols; untick it for a furniture-only plan - Circuit lines = the wiring runs you drew between devices. It sits with Electrical symbols: unticking Electrical symbols greys it out and leaves the lines out too - Exterior dimensions = on: each outside wall's overall length - Interior dimensions = on: each wall's measurement breaks where other walls meet it, so every room's inside width prints. The two are independent: untick Interior dimensions for overall outside lengths only, or Exterior dimensions for room sizes only. - Symbol legend & circuit table = on for an electrician: below the plan, every kind of outlet, switch and symbol with how many there are, and the list of circuits. It replaced the old Electrical plan checkbox - Labels = on (room names as your Label style shows them, plus furniture names and sizes if View & Layers shows them) - Room tints = off (saves ink) - Flooring = off (the default) for a working drawing. Tick it to print the tile, wood or carpet you picked for each room; it's only listed when a room's flooring would print, and Black & white greys it out. - Grid = off The measurement and label boxes start from what your plan shows in View & Layers: Furniture, Electrical symbols and Circuit lines follow Show furniture, Show outlets, switches & symbols and its Circuit lines row (see View & Layers); Exterior dimensions, Inside the rooms and Labels follow their rows, and Interior dimensions starts unticked only when both dimension rows are hidden. Sticky notes, Tape measurements and Tile layouts follow their rows as well, furniture names and sizes print only if Show furniture labels / Show furniture dimensions are on, and Flooring starts off, so glance at the boxes before you print. Saved a layout in the Tile Planner? Tick Tile layouts to print it for your tiler. See exporting a plan image for pictures of both options. Measurements and furniture don't fight on paper: since November 11, 2026 a number that would land under a dresser, a wardrobe or a run of cabinets moves along its line to a clear spot, or, if furniture fills the whole stretch, prints on top on a small white label. Where a line crosses furniture it prints lighter, so the furniture still reads. This matters most along interior walls, whose measurements always print inside the plan. In the web app, Elevation views adds the four exterior elevations as extra pages after the floor plan. On a multi-floor design, tick the floors to include.

  4. 5

    An electrician's plan: the Electrical plan view

    One design can give each trade its own sheet. The quickest electrician's sheet: in the Views row untick Floor plan and tick Electrical plan. Furniture, room tints and the room-by-room measurements go; the walls, doors and windows, the outside measurements, the room names, the outlets, switches and lights and every circuit run stay, and the Symbol legend & circuit table prints below the plan (a real export of it is shown in exporting a plan image). To do it by hand instead, untick Furniture and keep Electrical symbols and Circuit lines ticked: the plan prints with its walls, doors and windows, room names and measurements, the outlets, switches and lights, and every circuit run with its breaker label, but no beds, sofas or kitchen units in the way. We checked this on November 16, 2026 with a two-bedroom plan: with Furniture unticked the PNG had no furniture at all, while the outlets, the ceiling lights and the three circuit runs were all still there. Want just the outlets and switches, without the wiring? Keep Electrical symbols and untick Circuit lines. The boxes start from what your plan shows, so if you already hid the furniture with View & Layers → Show furniture they open unticked, and if the Electrical plan view is ticked in View & Layers it starts ticked here too. Changing them here doesn't change your plan. More on electrical drawings: the electrical floor plan guide.

    Electrical plan ticked, Floor plan unticked: no furniture, with the symbol legend and circuit table.
  5. 6

    A furniture plan: untick Electrical symbols

    For the furniture layout on its own (for a mover, a decorator or a buyer), untick Electrical symbols. The outlets, switches, lights and other plan symbols are left out, and so are the circuit lines: Circuit lines greys out, because a run has nothing to connect without its devices. In our test export of the same plan, the beds, sofa and kitchen printed with no symbols, no lights and no wiring.

    Furniture plan: Electrical symbols off, which takes the circuit lines with it.
  6. 7

    Sticky notes print as pins plus a Notes page

    If your plan has sticky notes, the options include Sticky notes, ticked when View & Layers → Show sticky notes is on. Each note prints as a small numbered pin where you placed it, and page 2 lists every note's full text by number. A PNG or JPG export saves the notes as a second image instead (one per floor on a multi-floor design). Untick Sticky notes to leave them out. Hiding notes in View & Layers also starts the box unticked. More in labels and sticky notes.

    Page 2: each pin number with the note's full text.

Tips

PDF is the share-and-print format

A PDF prints cleanly on any device and is easy to email or attach. Use black & white with measurements for a working drawing a contractor can build from.

Frequently asked questions

Can I print without saving a file first?

Yes. Use the Print tab in the Export / Print dialog: it sends the plan straight to your printer's dialog. Use the Export tab when you want a PDF to keep or send.

Do my sticky notes print?

Yes. With Sticky notes ticked (it starts ticked while View & Layers → Show sticky notes is on), each note prints as a numbered pin on the plan and the full text is listed on page 2. Untick it in the export dialog to print the plan without notes.

Why doesn't my flooring print?

Tick Flooring in the Options. It starts unticked, so the printout shows soft room tints instead. If the box isn't there, no room on the plan has flooring that would print (none picked yet, or the rooms changed after you moved walls: pick it again in Materials → Surfaces → Flooring Material); if it's greyed out, untick Black & white.

Can I print a plan without the furniture for my electrician?

Yes. In the Export / Print dialog untick the Floor plan view and tick Electrical plan: the furniture and room tints are left out, the outlets, switches, lights and circuit runs stay, and the symbol legend and circuit table print below the plan. Or just untick Furniture and keep Electrical symbols (and Circuit lines if you want the wiring). Your plan itself doesn't change. To hide furniture while you work, too, use View & Layers → Show furniture: see View & Layers.

Where did the Electrical plan checkbox go?

Since November 17, 2026 the dialog has a Views row above the Options with the same views as View & Layers. Tick Electrical plan there (and untick Floor plan for a sheet without furniture). The legend and circuit list are now their own option, Symbol legend & circuit table, which you can tick on any printout.

Can I print the outlets and switches without the circuit lines?

Yes: keep Electrical symbols ticked and untick Circuit lines. Unticking Electrical symbols instead leaves out the symbols, the lights and the lines.

Can I print without the room-by-room measurements?

Yes. Untick Interior dimensions and only the overall outside length of each wall prints. Untick Exterior dimensions too to print no wall measurements at all.

A measurement is hidden under furniture on my printout. What do I do?

Print or export it again. Since November 11, 2026 every number of the dimensions you tick stays readable: it slides along its line to a spot clear of furniture, or sits on a small white label on top of the furniture when there's no clear spot, and lines that cross furniture print lighter. Older printouts could lose a number under a dresser or cabinets, mostly along interior walls (which have no margin to move to). Pictures in exporting a plan image.

Can I print only the room sizes, without the outside lengths?

Yes. Untick Exterior dimensions and leave Interior dimensions ticked: each room's inside width and depth print, without the overall outside length of each wall.

PNG, JPG or PDF for printing?

PDF: it's one print-ready file that's easy to email, its page is already the paper size you picked, and the plan inside keeps crisp lines. Pick the paper size you'll print on so it's sharp at that size. Use PNG when you need an image to drop into a document or slide. A JPG prints fine at its default 85 % quality, but at low settings small numbers and thin lines come out soft, so don't print a low-quality JPG for a working drawing.

Why is my printed plan blurry on big paper?

Choose a higher Print quality (High or Max) on the Print tab, or, for a PDF, pick the real paper size (A1, A0, ARCH D…) with High or Max quality instead of Standard.

Can I print to scale (for example 1/4″ = 1′)?

Not at a fixed drawing scale. Print and Export → PDF/PNG/JPG fit the whole plan to the sheet: the drawing is enlarged or reduced to fill the paper you chose (with a small margin), so the scale on paper depends on how big your plan is and which paper you picked, and it won't land on a round architect's scale like 1/4″ = 1′ or 1:50. Every printout does carry a scale bar at the bottom left (0 to 3 ft, or 0 to 1.5 m) above the title block, plus the wall measurements, so anyone can check a size with a ruler against the bar. For a drawing that plots at an exact scale, use the web app's Export / Print / Share → DXF: the DXF is in true real-world units, and AutoCAD, LibreCAD or a print shop can plot it at 1/4″ = 1′, 1:50 or any scale you ask for. See exporting to DXF.

How do I show the outside dimensions of the building on the print?

Tick Exterior dimensions under Options (it's on both tabs). It prints the overall length of each outside wall, outer face to outer face, in a chain around the plan. The box starts the way Layers → Show exterior dimensions is set, so if you hid the outside measurements on screen, tick it here to print them. To see the same numbers while you work, open View & Layers on the toolbar and turn on Show exterior dimensions: see View & Layers. The outside lengths and the room-by-room Interior dimensions are independent, so you can print one, the other or both.

How do I get the total square footage (total area) of the plan?

Open Plan Settings and its Layout tab (top of the left panel on a computer; the Plan Settings button in the top row on a phone). It shows Gross area, the footprint measured to the outside faces of the outer walls, and Usable area, the floor inside the walls; a Balcony / Patio figure is listed separately when you have one. Each room's own area is on its room label, and the title block at the bottom of every printout and export shows the plan's overall width × depth with the same Gross area and Usable area (for example 30' x 26' | Gross area 811 sq ft · Usable area 750 sq ft). Add up the room labels and you'll usually get a little less than Usable area: the floor under the interior walls counts in Usable area but in no room (on the Backyard ADU (20 × 30) template the rooms add up to 562 sq ft against 573 sq ft Usable, and the difference is the three interior walls). A balcony or patio isn't in Gross or Usable area; its own area prints on the patio. More, with the full worked example, in inside room dimensions and areas; for the square footage of any rectangle you choose, use the tape measure's Area mode: tape measure tool.
