Elevation views — your home, straight on
Four straight-on exterior views of your building with real dimensions — viewable in the app and exportable for permits or contractors.
A floor plan looks straight down; an elevation looks straight at each side of the building, the drawing a permit office, a contractor or a window supplier expects next to the plan. RoomSketch3D draws all four sides for you from the design you already have, with the windows, doors and wall heights dimensioned, so there's nothing extra to draw.
An elevation answers the questions a plan can't: how high the windows sit, whether the window heads line up with the door heads, how tall the walls are, and how a railing or balcony meets the wall. On a typical 8 ft wall an interior door is usually 6 ft 8 in tall, and many builders line the tops of the windows up with the tops of the doors; the elevation shows at a glance whether yours do.
This page covers opening the elevation views (on any device), reading the dimensions, renaming the sides, and exporting them (in the web app).
What you'll need
- •Any design with walls (on a multi-floor design you view one floor at a time)
- •The web app on a computer or tablet browser to export them
Step by step
- 1
Open Elevation views
Tap the building icon, Elevation views, in the toolbar above the plan, just right of the purple cube (View in 3D). It's there at every screen size, in the browser and in the iPhone, iPad and Android apps.
The building icon opens the four elevations. - 2
Flip through the four sides
The sides open as tiles across the top: Top, Left, Bottom and Right, named for where each wall sits on your plan until you rename them. The highlighted edge on each tile's little plan shows which side you're looking at. On a multi-floor design, Floor at the bottom picks which floor to draw. Windows, doors, garage doors, balconies, railings, and bulkheads all appear where they'll really be. Each side takes a moment to draw: the window shows Loading… while it builds the first side, and switching to another side redraws it. On a computer that's about a second; on an older phone or tablet it can take a few seconds, and the dimension lines can show up on a blank background just before the walls do. Wait for the walls before you read the numbers.
The Right side of the Medium 2-Bedroom: 26' 6.5" outside face to outside face, the same number the plan shows, with each window and gap measured. - 3
Remember each side is seen from outside (left and right swap)
An elevation is what you'd see standing outside the building, facing that wall. The plan is what you'd see from above, with the top of the page as the top of the plan. So for some sides the elevation reads in the opposite direction from the plan:
Side You're standing Its left end is the plan's Its right end is the plan's Top above the plan's top edge, facing down the page right end left end Bottom below the plan's bottom edge, facing up the page left end right end Left left of the plan, facing right top end bottom end Right right of the plan, facing left bottom end top end In the Medium 2-Bedroom, the bedroom window near the left end of the top wall shows near the right end of the Top elevation. Nothing is wrong: that's how the wall really looks from the street or the garden, and it's how architects draw elevations. If you rename the sides (Street side, Garden side, North…), it's easier to remember where you're standing.
Same window, two views: near the left end on the plan, near the right end on the Top elevation, because the elevation is seen from outside. - 4
Read the dimensions
The overall wall height runs up one side and the wall length along the bottom, measured outside face to outside face, so it matches the outer dimension on the plan (the Medium 2-Bedroom's sides read 30' 6.5" and 26' 6.5" in both; before November 3, 2026 the elevation measured the wall centrelines and read 6.5" less). A second chain splits the wall into segments: wall, opening, wall, from outer corner to outer corner. For each window you also get the sill height (floor to the bottom of the window) and the head height (floor to the top). Dimensions switches the measurements off for a clean picture; Show outline switches the outline on or off. Known issue (November 2026): on the Top and Bottom sides the grey wall drawing currently stops about 7 to 8 inches short of the overall dimension line at one end, and the windows and doors sit a few inches off their marks on the chain below. The dimension numbers are right (they match the plan); it's the picture that's shifted, and a fix is on the way. The Left and Right sides line up. If you need a drawing for someone else, the numbers are the part to trust.
Segment widths along the bottom; sill and head heights on the window. - 5
Why a window's distance differs from the plan by the wall thickness
Tap a window or door on the plan and its settings show two distances under Along wall, marked ← and → (↑ and ↓ on a wall that runs up and down the page). Those are measured from the edge of the opening to the inside face of the wall it meets: the distance you'd tape inside the room. The elevation's chain measures the same wall from the outside corner of the building, because that's the end of the wall you see from outside. The two differ by the thickness of the wall at that end. Worked example in the Medium 2-Bedroom (outside walls 6.5" thick): the left window on the top wall reads ← 1′ 3.95″ under Along wall on the plan. On the Top elevation the gap between that window and the end of the wall reads 1′ 10.45″, and it's at the right-hand end because the view is from outside. 1′ 10.45″ − 1′ 3.95″ = 6.5″, exactly the wall's thickness. Both numbers are right; they're measured from different faces. Two more differences to expect: - Interior walls don't stop the elevation's chain. From outside you can't see them, so the elevation measures from one opening straight to the next. The same window's → distance on the plan is 5′ 2.55″ because it stops at the bedroom wall; on the elevation the gap to the next window reads 4′ 4.8″. - To go from one to the other, add the end wall's thickness to the plan's number (tap that outside wall: its panel shows Thickness), or use the plan's numbers when you're measuring inside the room and the elevation's when you're talking to someone working on the outside (siding, a window order, a permit drawing).
Plan: to the inside face. Elevation: to the outside corner. The 6.5″ difference is the wall. - 6
Rename the sides to match your lot
Tap the pencil on a tile (Name this side) and type a name: Street side, Garden side, North, whatever matches reality. Press Enter or tap the tick. The names are saved with the design and carry into your exports.
Name each side once; the exports use your names. - 7
Curved walls: openings go on straight walls for now
Doors, windows and outlets can't go on a curved wall yet. If you try, the wall flashes amber and a note says Doors, windows and outlets can't go on a curved wall yet. Place it on a straight wall, or straighten this one first. (While you're placing a window, its preview still lights up the curved wall as a straight line between its corners before the note appears; nothing is added.) To get a window into a curved stretch, split the wall first and curve only the piece without the window, or put the window on a straight wall; the curved walls guide walks through both.
- 8
Export (web app)
The Elevation views window has no download button. To export, open Export / Print / Share → PNG/JPG/PDF or Print and tick Elevation views under Options: with PNG you get the four sides as separate images, with PDF or Print they're extra pages after the plan. Black & white applies to them as it does to the plan. The option is only in the web app; the phone apps can view elevations but not export them. See Print your floor plan.
Tick Elevation views and the four sides go out with the plan.
Tips
Name the sides for your lot
Rename Top, Left, Bottom and Right (the sides as they sit on your plan) to something meaningful, such as street side and garden side, or the compass directions, so the set reads clearly to whoever receives it.
Export the full set
Tick Elevation views in the export dialog and the four sides go out with the plan: as separate images with PNG, or extra pages with PDF or Print (tick Black & white for line drawings). Send the plan (looking down) and the elevations (looking across) together for a complete package.
Line up window and door heads
Compare the head height of each window with the top of the doors on the same side. If they're a few inches apart, change the window's Height or Mount so the tops line up; it looks deliberate from outside.
One floor at a time
On a multi-floor design, use Floor at the bottom of the window to switch floors; each floor's walls are drawn on their own.
Common mistakes
Sending only the floor plan
Permit sets usually need elevations too. Generate and export all four sides, not just the plan view.
Skipping the wall heights
Elevations carry the wall and ceiling heights. Set those correctly in the plan first so the elevations come out right.
Fixing a size in the wrong place
The Elevation views window is for looking. To change a window or door, close it, tap the window or door on the plan, edit its size there, and reopen the elevation to check.
Frequently asked questions
How do I open elevation views?
Tap the building icon (Elevation views) in the toolbar above the plan, right of the purple 3D cube. It's there on every screen size, including the iPhone, iPad and Android apps. The four sides open as tiles: Top, Left, Bottom and Right, until you name them.
Are the elevations dimensioned?
Yes. The overall wall height and length, the width of every wall segment and opening, and each window's sill and head height are dimensioned automatically. Dimensions turns them off for a clean picture.
Can I rename the sides?
Yes. Tap the pencil on a side's tile (Name this side), type a name such as street side or garden side, and press Enter. The name is used on the exported elevation too.
How do I export them?
The Elevation views window is for looking; it still has no download button (checked November 9, 2026). To export, open Export / Print / Share → PNG/JPG/PDF or Print and tick Elevation views under Options: four separate images with PNG or JPG (the dialog's file count includes them), four extra pages with PDF or Print. This option is only in the web app (on a computer or tablet browser); the phone apps can view elevations but not export them.
Can I see all floors stacked in one elevation?
The Elevation views window draws one floor at a time; pick it with Floor. For the whole house at once, use the 3D view.
Why is the window on the other side in the elevation?
Because each elevation is drawn as you'd see that wall standing outside the building, facing it, while the plan is seen from above with the top of the page at the top. For the Top side you're standing beyond the plan's top edge looking back down the page, so it reads right to left compared with the plan: a window near the left end of the top wall shows near the right end of the Top elevation. The Bottom side reads the same way round as the plan; for Left and Right, the table in the step Remember each side is seen from outside (above) shows which end of the plan each end of the elevation is. Nothing is wrong: that's how the wall really looks from the street or garden, and how architects draw elevations. Renaming the sides (Street side, Garden side) makes it easier to remember where you're standing.
Why doesn't the elevation match the window's Along wall distance on the plan?
They're measured from different faces. The plan's two Along wall distances (← / →) run from the opening to the inside face of the wall it meets (what you'd tape inside the room). The elevation's chain runs from the building's outside corner, the end of the wall you see from outside. So the two differ by the thickness of the end wall: 6.5″ for the outside walls of the RoomSketch3D templates. In the Medium 2-Bedroom Apartment, the left window on the top wall reads ← 1′ 3.95″ under Along wall on the plan and 1′ 10.45″ to the end of the wall on the Top elevation (at its right-hand end, because that side is seen from outside): 6.5″ apart. Interior walls also don't stop the elevation's chain, since you can't see them from outside, so an Along wall distance that stops at an inside wall won't appear on the elevation at all. Both sets of numbers are right. The step Why a window's distance differs from the plan by the wall thickness (above) has the picture.
Why is one side blank?
A wall with no windows or doors draws as a plain rectangle with just its height and length. That's normal; add the windows and doors on the plan and they appear in the elevation.
