Murphy beds — a bedroom that folds away

Mount a Murphy bed on any wall, choose the mattress size, and toggle it open to check the room still works.

6 min readUpdated 2026-11-16

A Murphy bed is the classic small-space move: a real bed by night, a slim cabinet by day. RoomSketch3D models both states. Closed, it's an 18-inch-deep cabinet against the wall; open, it folds down to the full length (or width) of the mattress you choose, and Smart Flow Check makes sure nothing stands in its way.

The question that matters is how much floor the open bed needs. Manufacturers' size guides put a vertical Queen at about 85 to 90 in from the wall when open and a horizontal Queen at about 65 to 68 in, with 30 to 36 in of clear floor recommended along the sides you use. Add those up and a vertical Queen wants roughly 9½ to 10½ ft of room depth for a comfortable path past its foot; a horizontal Queen about 8 to 8¾ ft.

This page covers adding a Murphy bed, choosing the mattress size and fold direction, opening it to check the room, what Flow Check tells you, and how to allow for the real unit you buy.

What you'll need

  • •A room with a free wall long enough for the cabinet (60 in for a Queen standing vertically)

Step by step

  1. 1

    Find the Murphy bed in the catalog

    In the catalog on the right, type Murphy (or wall bed, fold-down bed) into Search Furniture & Fixtures. It's listed under Beds and on the Bedroom tab. Tap the Murphy Bed tile, then +Add.

    Search Murphy, wall bed or fold-down bed.
  2. 2

    Mount it on a wall

    Move the pointer to the wall the bed folds out from and tap. The bed mounts on the wall like a window or door and starts Closed: an 18-inch-deep cabinet, 60 in wide for the default Queen standing Vertical. Its settings open (a floating card on a tablet or computer, a panel along the bottom on a phone) with Along wall (its position along the wall: two boxes with arrows, ↑ ↓ on a wall that runs up and down the plan, ← → on one that runs across), Closed / Open, Size and Vertical / Horizontal.

    Closed, it's an 18-inch cabinet; its settings hold every Murphy option.
  3. 3

    Pick the mattress size

    Size offers Twin, Twin XL, Full, Queen, King and Cal King. The cabinet width and how far the open bed reaches into the room follow from the mattress (measured from the wall, in inches):

    SizeMattressVertical: cabinet / opensHorizontal: cabinet / opens
    Twin38 × 7538 / 7575 / 38
    Twin XL38 × 8038 / 8080 / 38
    Full54 × 7554 / 7575 / 54
    Queen60 × 8060 / 8080 / 60
    King76 × 8076 / 8080 / 76
    Cal King72 × 8472 / 8484 / 72

    The width can't be typed freely: it always matches the mattress you pick.

  4. 4

    Choose Vertical or Horizontal

    Vertical stands the mattress on end: a narrower cabinet that opens deep into the room. Horizontal lays it sideways: a wider cabinet that opens less far, which suits a narrow room, a wall under a window, or a sloped ceiling. The same Queen reaches 80 in into the room vertical and 60 in horizontal.

    Horizontal: a wider cabinet, a shallower bed.
  5. 5

    Flip it open and furnish around it

    Tap Open to see the bed down. Furnish with it open: the footprint is the whole mattress plus the cabinet strip at the wall. In this 9' 5.5" wide bedroom the open vertical Queen leaves about 33 in between its foot and the opposite wall, just under the 36 in usually planned for a walkway. Pieces standing where the bed folds down (a nightstand, a chair) still show on the plan over the open mattress (since November 3, 2026; before, the open bed hid them), and Flow Check lists each one.

    Open, the Queen reaches 80 in into the room.
  6. 6

    Let Flow Check guard the open footprint

    Flow Check checks both states. With the bed closed, anything standing where the bed will land gets a warning: Accent Chair is in the Murphy bed's path, The bed is closed now, but it'll hit this when it folds down. With the bed open, the same chair becomes an issue to fix: Accent Chair blocks the Murphy bed. Two Murphy beds whose open footprints overlap get Two Murphy beds would collide.

    Closed bed, chair in its path: Flow Check warns before the bed ever comes down.
  7. 7

    Check the room in 3D

    Open View in 3D. Closed, the bed reads as a clean cabinet; open, the mattress lies on the floor in front of it, so you can judge how much room is left to walk past.

    Open in 3D: the cabinet stays on the wall, the mattress comes down.

Tips

Allow for the real cabinet, not just the mattress

RoomSketch3D sizes the open bed from the mattress: a vertical Queen reaches 80 in into the room. Real units add the frame and cabinet, so their spec sheets usually say more (85 to 90 in for a vertical Queen). Keep that extra few inches clear beyond the bed's foot, and measure it with the tape measure tool.

Leave room to walk and make the bed

Size guides recommend 30 to 36 in of clear floor along the sides of the open bed you use. With the bed open, check the gap at its foot and its open side.

Sideways fold for a low or narrow wall

Under a window, under a sloped ceiling, or in a narrow room, set Horizontal: the cabinet is wider and lower, and the bed comes out 20 in less far for a Queen.

Pair it with furniture that moves

A desk, a table on casters, or a lightweight chair can sit in the bed's path by day if you'll move it at night; Flow Check will still warn, which is a useful reminder of what has to move.

Common mistakes

Planning only for the closed state

It's easy to fit the cabinet and forget the bed. Open it while you furnish: Flow Check reserves the open footprint and flags anything in its path.

Two Murphy beds that can't both open

If two Murphy beds share a room, Flow Check warns when their open footprints collide. Stagger them so both can fold down.

Ignoring the piece drawn over the mattress

With the bed open, anything standing where it folds down is drawn on top of the mattress on the plan (it used to be hidden under it), and Flow Check lists it as blocking the bed. Move it, or the bed.

Forgetting the door swing

A bedroom door that swings into the bed's footprint will hit it. Flip the door's swing or place the bed on another wall.

Frequently asked questions

How do I add a Murphy bed?

Search the catalog for Murphy, tap the Murphy Bed tile, tap +Add, then tap the wall it mounts on. It starts closed, as an 18-inch cabinet.

What mattress sizes are available?

Twin, Twin XL, Full, Queen, King and Cal King. Select the bed and pick one under Size; the cabinet width follows the mattress.

How deep is a Murphy bed when open?

In RoomSketch3D the open bed reaches the mattress length (vertical) or width (horizontal) into the room: 80 in or 60 in for a Queen. Real units add the frame: size guides list about 85 to 90 in for a vertical Queen and 65 to 68 in for a horizontal one. Check your model's spec sheet.

How much room do I need for a Murphy bed?

Open depth plus a walkway. For a vertical Queen that's about 85 to 90 in plus 30 to 36 in, roughly 9½ to 10½ ft from the wall. A horizontal Queen needs about 8 to 8¾ ft (65 to 68 in plus the same walkway).

Does the plan account for the bed when it's open?

Yes. Flow Check checks the open footprint in both states: a warning while the bed is closed (… is in the Murphy bed's path) and an issue to fix while it's open (… blocks the Murphy bed).

Can it fold down sideways?

Yes. Choose Vertical or Horizontal in its settings, whichever your wall allows.

Can I type a custom width?

No. The Murphy bed's width always matches the mattress size and orientation you pick, so there's no free width box.
