Adding columns, radiators, and other obstacles
Mark the things you can't move — columns, radiators, ducts — so your furniture layout works around them.
Columns, radiators, ductwork, and chimney breasts are obstacles — fixed elements furniture has to work around. Place them like any wall fixture and Smart Flow Check accounts for them.
They're easy to forget when you measure a room, and they're exactly what makes a layout fail on moving day: the sofa that fits the floor plan but not the gap between the column and the wall, the bookcase that ends up in front of the radiator. Here's how to add each kind in RoomSketch3D, how big to make it, and what Flow Check does with it, shown on the Cozy Living Room template.
Step by step
- 1
Pillar (column)
Open the Build panel (on a phone, Structural & Interior) and tap Pillar in the Structural section. The pillar appears in open floor near the middle of the plan, already selected, never inside a wall or under a rug, table or sofa (since November 3, 2026; before, it always landed dead centre and could hide under furniture): drag it to where the column really stands. In its settings, set Width and Depth (each 4 to 72 inches; it starts at 12 × 16), Height (it follows the wall height until you change it) and Rotation. The pillar is always rectangular; it shows in 2D as a small filled shape and in 3D as a full-height column. The Rotation button turns it a quarter-turn at a time (0°, 90°, 180°, 270°). Height can be anything from 12 in to 20 ft, and the Reset to room default option puts it back to the wall height. Tap a size to type it: in feet and inches the box splits into ft and in, so a 16-inch column is 1 ft 4 in.
Drag the pillar where the column stands, then type its Width, Depth and Height in its settings. - 2
Where a new pillar lands
In the Cozy Living Room the new 1' × 1' 4" pillar came in just left of the rug, in clear floor, with Flow check OK. Only if there's no clear spot at all (a plan carpeted wall to wall) does it go onto a rug, and as a last resort the middle of the plan. A second pillar never lands on top of the first. Stairs, elevators, floor openings and sunken areas aren't avoided, so check it isn't sitting on one.
Cozy Living Room: the new pillar lands in open floor near the middle, beside the rug. - 3
Let Flow Check catch what's in the way
Once the pillar is in, Smart Flow Check treats it as solid: any piece standing on its footprint turns red and the Flow check button shows a count. Tap it for the list. The message reads Coffee Table (Rect) overlaps pillar: Move it so it doesn't share the column footprint. Rugs never count, and a wall-mounted piece that hangs above the top of a short pillar doesn't either. In the picture the pillar was dragged into the middle of the Cozy Living Room, right under the coffee table, so the table is flagged. Furniture draws on top of a pillar on the plan, so the pillar is hidden under the table; to grab it, tap the spot and choose Pillar from the Select item list that appears when pieces are stacked.
A pillar under the coffee table: Flow Check flags the table until one of them moves. - 4
Radiator
Radiators are catalog items. In Furnish, search radiator (they also sit in the Bathroom room tab) and pick Compact, Standard, Wide or Tall Vertical Radiator. Drag it against the wall and set its exact size in its settings. Real residential radiators run about 24–48 inches wide and 18–30 inches tall.
Radiators hang on a wall: after +Add, a blue bar asks you to tap a wall to place it, and the radiator snaps flat to that wall. Its settings then show Mount (the height of its bottom edge above the floor, 4 in to start), Other side to move it to the opposite face of the wall, and the usual width, depth and height. The catalog sizes:
Radiator Width × depth × height Compact 18 × 4 × 18 in Standard 30 × 4 × 22 in Wide 48 × 4 × 22 in Tall Vertical 12 × 4 × 60 in Search radiator, tap +Add, then tap the wall it hangs on. - 5
Other obstacles
Ductwork, chimney breasts, built-in cabinetry, plumbing chases — model with the Pillar tile (sized accordingly), or add the closest catalog piece (a cabinet, a shelf) and type its exact size in its panel.
A chimney breast is a pillar pushed against the wall, as wide as the breast and as deep as it sticks out; a boxed-in duct running up a corner is a narrow pillar in that corner. Measure what sticks out into the room, not the hidden part inside the wall: what matters for furniture is the floor it takes up.
Which tool for which obstacle:
Obstacle Add it with Notes Structural column, post, boxed-in beam support Build → Structural → Pillar Rectangle, 4–72 in each way; any height Radiator Furnish, search radiator Hangs on a wall; four sizes, all resizable Chimney breast, boxed-in duct or pipe chase Pillar sized to match Push it against the wall Built-in cabinetry, bench, window seat The closest catalog piece Type its exact size The finished plan: a column in the corner and a radiator under the window, with the furniture clear of both. - 6
Check it in 3D
Open View in 3D. The pillar stands as a solid column from floor to its height, the radiator hangs on its wall at its mount height. Orbit round to the side of the room where they are and check what's left: the gap between a column and the sofa arm, whether the chair still fits beside the radiator, whether the column blocks the view from the door.
In 3D: the column runs floor to ceiling, the radiator sits low on the side wall.
Tips
A pillar is a rectangle
A pillar has no round option: it's always a rectangle. For a square post, type the same Width and Depth. For a round column, use a square of the column's diameter so the clearance around it stays honest.
Model the radiator too
Add the radiator from the catalog (search radiator) so Flow Check flags furniture that overlaps it, not just structural columns.
Place the obstacles before the furniture
A new pillar lands in the nearest clear floor to the middle of the plan, clear of walls, rugs and furniture, so it's always visible. You still drag it to where the real column stands, and furniture is easier to arrange around columns, radiators and chases that are already in place, so add those first.
Leave the radiator room to breathe
A sofa pushed hard against a radiator blocks the warm air and dries out the upholstery. Keep a gap in front of it and keep tall pieces off it; check your radiator's own instructions for how much space it wants.
Use Height for half-height obstacles
A pillar's Height doesn't have to reach the ceiling. A 36-inch boxed pipe or a knee-height ledge is a pillar with its Height typed in, so the 3D view shows it the way it really is.
Common mistakes
Treating a column as furniture
A pillar is structural — it runs floor to ceiling and furniture must clear it. Place it with the Pillar tile so Flow Check flags anything overlapping it.
Guessing the size
A boxed-in steel post can be 6–12 in; a masonry column more. Measure the real one and set the size, or your clearances will be off.
Putting the radiator on the outside of the wall
Where you tap the wall decides which face the radiator goes on. If it ends up outside the room (you'll see it beyond the wall line on the plan, and outdoors in 3D), select it and tap Other side.
Losing a pillar under a rug or table
On the 2D plan furniture draws over a pillar, so a pillar under a coffee table is hidden and only the table's red outline gives it away. Tap the spot and pick Pillar from the Select item list, or move the furniture first.
Frequently asked questions
How do I add a column?
Build → Structural → Pillar. It lands in open floor near the middle of the plan, selected; drag it into place and set its Width and Depth.
How does Smart Flow Check treat a column?
It's an obstacle — furniture must clear it. Flow Check warns when a piece overlaps the column footprint, so route seating and tables around it.
Can I model a radiator or chimney breast?
Yes. A radiator comes from the catalog (search radiator in Furnish). A chimney breast or boxed-in chase is a Pillar sized to match. Either way Flow Check keeps furniture clear of it.
Can a pillar be round?
No: a pillar is always rectangular. Type the same Width and Depth for a square post, or use a square the size of a round column's diameter.
I added a pillar but can't see it. Where did it go?
A new pillar lands in clear floor near the middle of the plan, so it shows. If you moved it under a rug, table or sofa, furniture draws on top of it: the piece over it turns red in Flow Check. Tap that spot and choose Pillar in the Select item list to select it. (Before November 3, 2026 a new pillar always landed dead centre, often under the coffee table.)
My radiator is on the outside of the house. How do I fix it?
Select it and tap Other side in its settings. It moves to the other face of the same wall.
Can a pillar be shorter than the ceiling?
Yes. Type its Height (12 in up to 20 ft). Until you do, it follows the wall height.
