Pillars and load-bearing columns

Free-standing vertical supports — structural (carrying load) or decorative. Sizes, code minimums, placement, and how Flow Check keeps furniture off them.

4 min readUpdated 2026-11-16

A pillar or column is a free-standing vertical support. In residential floor plans, most columns are structural — carrying load from beams or roof above.

Quick answer: draw a column at its real outside size (a steel lally column is often 3–4 inches across, a wood post 4–6 inches square before any boxing-in, a finished decorative column 8–16 inches), and plan furniture and walkways around it — a structural column doesn't move.

The example below puts a 12 × 12 inch boxed column in a 18 × 16 ft living room, next to the walkway, and shows what Flow Check does when furniture lands on it.

The pillar lands in clear floor near the middle of the plan; drag it into place. Width, Depth, Height and Rotation are in its panel.

In this guide

  1. 1

    Structural columns

    Carry vertical loads from beams, floors, or roof. Common positions: mid-room column supporting a long beam (open-plan houses); porch columns supporting porch roof; basement lally columns supporting first-floor beams. Standard sizes: 4-8 inches diameter (steel lally), 6-12 inches square (wood post), 8-24 inches diameter (decorative round). Code minimums: the 2021 IRC requires wood columns to be at least 4 × 4 inches nominal and steel columns at least 3-inch-diameter Schedule 40 pipe (R407.3), restrained at the bottom. The actual size is set by the load — an engineer or the beam supplier's tables decide it.

    A 12" × 12" column beside the walkway in a living room.
  2. 2

    Decorative columns

    Architectural detail with no structural role. Often at room entries, gallery walls, exterior porches. Sized for visual effect — 8-16 inches diameter or square. Many "decorative" columns are actually a structural post wrapped in a larger box or round cover. Ask before you plan to remove one.

  3. 3

    Where columns matter for layout

    Structural columns can't move. They dictate furniture placement and walkway routing. Decorative can be relocated during renovation. Plan around a column the way you plan around a wall corner: keep a 36-inch walkway past it, don't put it in front of a TV or between a sofa and its coffee table, and use it — a column can anchor a reading chair, a plant or the end of a sofa.

    The column runs floor to ceiling in 3D.
  4. 4

    Flow Check keeps furniture off it

    Flow Check treats a pillar as solid: if a piece of furniture overlaps the column's footprint, it reports "Side Table overlaps pillar" with Move it so it doesn't share the column footprint. Rugs are exempt (they lie under everything), and so is anything mounted entirely above the pillar's top.

    A side table on the column: Flow Check flags it.
  5. 5

    In RoomSketch3D

    In the left panel's Structural section tap Pillar. There is no second tap: a 12 × 16 inch column appears straight away in open floor near the middle of the plan (never in a wall or under a rug or furniture). Drag it to where the column really is. Select it and its panel shows Width, Depth, Height (it starts at the room's ceiling height; reset brings it back) and Rotation (with a Rotate 90° button). Pillars are always rectangular; there is no round option, so for a round column set Width and Depth to its diameter.

    Pillar: Width, Depth, Height and Rotation.

Tips

Measure the finished size

Draw the column at the size you'll see (including any box or wrap), not the steel or wood inside it — that's what furniture has to clear.

Common confusions

Assuming a boxed column is decorative

Many boxed columns hide a structural post. Treat every column as structural until a contractor confirms otherwise.

Frequently asked questions

Can I make a round column in RoomSketch3D?

Not as a round shape — pillars are rectangular. Set Width and Depth to the column's diameter for a square stand-in of the same size.

How big is a typical residential structural column?

4-8 inches diameter for steel lally; 6-12 inches square for wood post; 8-24 inches for decorative round. Code minimums are smaller (4 × 4 nominal wood, 3-inch Schedule 40 steel pipe, 2021 IRC R407.3); the load decides the real size.

Does Flow Check warn about furniture on a pillar?

Yes — it reports "overlaps pillar" for any furniture that shares the column's footprint (rugs excepted).
