Flooring options — every material, tone, and plank size

A reference to every floor the app can lay: three indoor materials with their full color palettes and hardwood plank sizing, plus the outdoor ground covers yards use — all applied per room and rendered in 2D and 3D.

5 min readUpdated 2026-11-17

Flooring lives in Materials → Surfaces → Flooring Material (on a computer, the Surfaces tile in the left panel's Materials tab; on a phone, the Materials button under the plan). Tap any room on the small plan to assign a material; the live 3D view in the popup shows that floor as you pick, and the cube in the header (View in 3D) opens the full 3D view without losing your selection. Wall Paints and Ceiling Paints are the tabs next to it.

Indoors there are three materials — Tile, Hardwood, Carpet — each with two kinds of finish: Materials (photo textures) and Colors (plain tones). None clears a room back to the plain canvas. Outdoor floors (yards) swap the list for ground covers. Everything renders in both the 2D plan and the 3D view, patterns included. To put the floors on a PNG, PDF or printout, tick Flooring in the export dialog (it starts unticked).

Why bother with flooring in a floor planner? Because the floor changes how a room reads more than almost anything else: a dark floor makes a small room feel smaller, a wide light plank makes it feel calmer and bigger, and a change of material at a doorway tells you where one space ends. Trying three options on your real plan takes a minute and shows you the combination before you order samples.

In this guide

  1. 1

    Open the flooring picker

    On a computer, open the Materials tab at the top of the left panel and click Surfaces (Flooring, wall paints and ceiling paints). On a phone, tap the Materials button under the plan. The Surfaces popup opens on Flooring Material: a small copy of the current floor on the left, a live 3D preview on the right, and the hint Click anywhere on the plan to set its flooring. Click a room on the small plan to select it (it gets a blue outline and its size, such as 9.5′ × 15.5′, heads the panel), then pick None, Tiles, Hardwood or Carpet. Each material has a Materials row (photo textures) and a Colors row (plain tones). The 3D preview shows that one room from above; drag it to look around.

    Flooring starts here: Materials → Surfaces. Tile Planner and Picture Gallery sit underneath.
  2. 2

    Hardwood — 12 tones, your plank size

    Four photo finishes under Materials: Oak, Herringbone, Dark Plank, and Rustic Plank (a new hardwood floor starts on Oak). Under Colors, twelve plain wood tones: Oak, Maple, Walnut, Grey Wash, Espresso, Honey Oak, Natural Pine, Cherry, Hickory, White Oak, Whitewashed, and Ebony (hover a swatch on a computer to see its name). Once a plain tone is picked, Width and Length boxes appear so you can size the planks like the real product: Width offers 3¼″, 5″, 7″, 8″, 10″ or 1′ (5″ to start), Length offers 3′, 4′, 6′, 8′, 10′ or 12′, and Other… on either lets you type your own (width 1½″ to 16″, length 1′ to 16′). Planks draw in a staggered running bond, the way a floor is actually laid, so a 7″ plank reads noticeably wider than a 3¼″ strip both on the plan and in 3D.

    Hardwood, Colors, Oak: the Width and Length boxes (here 7″ × 6′) change the planks on the small plan and in the live 3D view.
  3. 3

    Tile — seven photo finishes and six colors

    Photo finishes under Materials: Porcelain, Patterned Tile, Checkerboard, Travertine, Carrara Marble, Crema Marble, and Terrazzo. Under Colors, a clean 12″ grid in Light Grey, White, Beige, Slate, Charcoal, or Terracotta: the usual pick for bathrooms, kitchens, laundry rooms and mud rooms, where the grid also helps you read scale at a glance. The tile finishes here are for the look. To plan real tile sizes, grout, starting lines, cuts and box counts, open the Tile Planner from the same Materials tab.

    Tiles, Materials, Carrara Marble on the bathroom. The small plan already shows the oak living room and carpeted bedroom next to it.
  4. 4

    Carpet — three textures, six soft colors

    Three photo finishes under Materials (Gray Loop, Beige Pattern, and Berber), or a soft texture under Colors in Beige, Greige, Dove Grey, Cream, Charcoal, or Navy: bedrooms and dens, typically. A bold photo texture like Gray Loop is easy to spot on a busy plan; a plain color keeps the plan calm and lets the furniture stand out. Like every material, carpet stops exactly at the room's walls and follows the room's real shape, alcoves and openings included.

    Carpet, Colors, Greige on the bedroom. Apply to all rooms sits under every material.
  5. 5

    See the floors on the plan

    Close the popup and the floors are on the main plan: wood planks, marble and carpet, each clipped to its room. They're controlled by Show flooring in View & Layers (the stacked-sheets button, first in the toolbar above the plan; the row is in the Floors, ceilings & yard group). It switches on by itself when you give a room a floor, and ticking the Interior design view turns it on too. Untick it when you want a plain, uncluttered plan to measure or furnish on; your flooring choices stay saved and come back when you tick it again. Rooms with no flooring (None) keep their soft room color.

    View & Layers → Show flooring: the oak Great Room floor drawn on the plan.
  6. 6

    See the floors in 3D

    Click the purple cube (View in 3D) in the toolbar, or the cube in the Surfaces popup's header, to see every room's floor in the full 3D view. Tick Dollhouse to cut the front walls away and look straight into the rooms; the plank direction, tile veining and carpet color all match what you picked. From here you can walk through the rooms or save an image to compare options side by side.

    The same floors in 3D with Dollhouse on: oak planks in the living area, marble in the bathroom.
  7. 7

    Outdoor ground covers — for yards

    On a yard floor the popup is titled Ground Cover and shows only that list (no wall or ceiling paints outdoors): lawn (four greens from Fresh to Dry), pavers (16″, in slate/sandstone/terracotta/charcoal, with grid, running-bond, and diagonal layouts), concrete (48″ panels), deck boards (cedar, redwood, weathered grey, ipe), gravel, mulch, tanbark, and asphalt. Yard zones — driveway, walkway, patio, play area — each take their own cover.

Tips

Set the whole floor first, then override rooms

Set one room, tap Apply to all rooms (and again to confirm) to give every room on the floor the same flooring, then re-tap just the rooms that differ — tile in the bath, carpet in the bedroom. It's faster than doing every room from scratch.

Match your real plank

Flooring boxes state the plank size — enter it with Other… and the 3D view previews the actual product you're deciding on, not a generic floor.

Plan the transitions, not just the rooms

Where hardwood meets tile or carpet at a doorway, a real floor needs a transition strip. Setting each room separately shows you exactly where those changes fall: in the example above the change sits in the bedroom and bathroom doorways, which is where you'd want it. A material change in the middle of an open area usually looks like a mistake.

Order a little extra

The app shows the look, not a shopping list for planks. A common guideline is to buy about 10% more than the room's floor area to cover cuts and waste, more for diagonal or herringbone patterns. Each room's size heads the flooring panel when you select it (for example 9.5′ × 15.5′, about 147 sq ft); for tile, the Tile Planner counts tiles and boxes for you.

Want a material we don't have?

Tell us through the in-app Support menu (feature request) — flooring patterns are exactly the kind of thing we add from customer asks.

Common confusions

Looking for flooring on the wrong tab

Flooring is under Materials → Surfaces → Flooring Material, next to Wall Paints and Ceiling Paints — not in the furniture catalog. (Gym flooring mats are the exception: they're placeable items in the Gym category.)

Expecting wall paint here

Floors, walls and ceilings each have their own tab in the Surfaces popup: wall colors live in Wall Paints and ceiling colors in Ceiling Paints, right beside Flooring Material, with their own brand-color catalog.

Frequently asked questions

Why don't I see Width and Length for my hardwood?

They appear for the plain wood tones under Colors. The four photo finishes under Materials (Oak, Herringbone, Dark Plank, Rustic Plank) use their own fixed pattern. Switch to Colors, pick a tone, and the plank boxes show up below the swatches.

My floor doesn't show on the plan. What's wrong?

Check View & Layers → Show flooring (the stacked-sheets button in the toolbar above the plan); if it's unticked, floors are hidden on the plan (they still show in 3D). The choice is saved with each design, so a design you hid it in stays that way on every device. If it's ticked, open Materials → Surfaces and click the room: it may be set to None. Flooring is per room, so a space without walls around it can't take its own floor until it's a room.

Can two rooms share one continuous floor?

Give both rooms the same material and tone and the pattern reads as continuous across the opening — each room still keeps its own setting, so you can change one later.

Does flooring show in exports?

Yes, when you ask for it. In Export / Print / Share → PNG/JPG/PDF or Print, tick Flooring: it starts unticked, so a plain export shows each room's soft color tint instead. With it ticked, every room with flooring prints its tile, wood or carpet. The box only appears once a room has flooring, and it's greyed out with Black & white. The 3D view and the GLB model always show your floors. See exporting a plan image for a before-and-after.

Is there a cost per material?

No — every material, tone, and plank size is included in the one-time purchase, like the rest of the app.

Can I use a photo of my own tile, wood, or fabric as a material?

No — the 3D materials are the built-in set (hardwood tones, tiles, carpets, outdoor covers, and the paint brands). Pick the closest tone and plank or tile size, and match colors exactly with a custom color on furniture. If a material you'd use is missing, tell us from Support → Request a feature; materials are added regularly.
